socomec DIRIS A40 User Manual

DIRIS A40/A41 - RS485 - JBUS/MODBUS
®
GB
93
DIRIS A40/A41 - Ref.: 536 103 B GB
COMMUNICATION
Decimal Hexa. Number Text Unit
address address of words
4066 FE2 1 Day
4067 FE3 1 Month
4068 FE4 1 Year
4069 FE5 1 Hour
4070 FE6 1 Minute
4071 FE7 1 Second
4072 FE8 2 THD 3V maximum 0.10 %
4074 FEA 1 Day
4075 FEB 1 Month
4076 FEC 1 Year
4077 FED 1 Hour
4078 FEE 1 Minute
4079 FEF 1 Second
Zone size: 240 words (decimal) or FO (hexadecimal).
MINIMUM AND MAXIMUM INSTANTANEOUS VALUES (FUNCTION 3)
Decimal Hexa. Number Text Unit
address address of words
4096 1000 1 Day
4097 1001 1 Month
4098 1002 1 Year
4099 1003 1 Hour
4100 1004 1 Minute
4101 1005 1 Second
LAST 10 VOLTAGE CUT-OFFS EVENT LOG / SAG (FUNCTION 3)
Outage n-1
Decimal Hexa. Number Text Unit
address address of words
4102 1006 1 Day
4103 1007 1 Month
4104 1008 1 Year
4105 1009 1 Hour
4106 100A 1 Minute
4107 100B 1 Second
Outage n-2
Decimal Hexa. Number Text Unit
address address of words
4108 100C 1 Day
4109 100D 1 Month
4110 100E 1 Year
4111 100F 1 Hour
4112 1010 1 Minute
4113 1011 1 Second
Outage n-3
Decimal Hexa. Number Text Unit
address address of words
4114 1012 1 Day
4115 1013 1 Month
4116 1014 1 Year
4117 1015 1 Hour
4118 1016 1 Minute
4119 1017 1 Second
Outage n-5

socomec DIRIS A40 Specifications

General

Type	Multifunction Meter
Display	LCD with backlight
Operating Temperature	-10 to +55 °C
Mounting	Panel mounting
Measurement Parameters	Voltage, Current, Power, Energy, Frequency
Communication	RS485, Modbus RTU
Storage Temperature	-25°C to +70°C
Protection Degree	IP20
Standards	IEC 61557-12
Accuracy	Class 0.5
Dimensions	96 x 96 mm
