DIRIS A40/A41 - RS485 - JBUS/MODBUS
®
GB
89
DIRIS A40/A41 - Ref.: 536 103 B GB
COMMUNICATION
Decimal Hexa. Number Text Unit
address address of words
3710 E7E 1 Query! : maximum phase-to-phase value :
0 : no
5: U12
6: U23
7: U31
3711 E7F 2 Value
3713 E81 1 Query! : maximum phase-to-neutral value :
0 : no
22 : V1
23 : V2
24 : V3
3714 E82 2 Value
3716 E84 2 Duration ms
3718 E86 1 Day
3719 E87 1 Month
3720 E88 1 Year
3721 E89 1 Hour
3722 E8A 1 Minute
3723 E8B 1 Second
Decimal Hexa. Number Text Unit
address address of words
3840 F00 2 3I minimum mA
3842 F02 1 Day
3843 F03 1 Month
3844 F04 1 Year
3845 F05 1 Hour
3846 F06 1 Minute
3847 F07 1 Second
3848 F08 2 3I maximum mA
3850 F0A 1 Day
3851 F0B 1 Month
3852 F0C 1 Year
3853 F0D 1 Hour
3854 F0E 1 Minute
3855 F0F 1 Second
3856 F10 2 IN minimum mA
3858 F12 1 Day
3859 F13 1 Month
3860 F14 1 Year
3861 F15 1 Hour
3862 F16 1 Minute
3863 F17 1 Second
3864 F18 2 IN maximum mA
3866 F1A 1 Day
3867 F1B 1 Month
3868 F1C 1 Year
3869 F1D 1 Hour
3870 F1E 1 Minute
3871 F1F 1 Second
3872 F20 2 3U minimum mA
LAST 10 TEMPORARY VOLTAGE SURGE EVENT LOG (FUNCTION 3)
Voltage surge n-10
MINIMUM AND MAXIMUM INSTANTANEOUS VALUES (FUNCTION 3)
Zone size: 140 words (decimal) or 8C (hexadecimal).

socomec DIRIS A40 Specifications

General

Type	Multifunction Meter
Display	LCD with backlight
Operating Temperature	-10 to +55 °C
Mounting	Panel mounting
Measurement Parameters	Voltage, Current, Power, Energy, Frequency
Communication	RS485, Modbus RTU
Storage Temperature	-25°C to +70°C
Protection Degree	IP20
Standards	IEC 61557-12
Accuracy	Class 0.5
Dimensions	96 x 96 mm
