DIRIS A40/A41 - RS485 - JBUS/MODBUS
®
GB
13
DIRIS A40/A41 - Ref.: 536 103 B GB
A : NEW COMMUNICATION TABLE FROM 01/2009
4 > TABLE C850 Hex
Decimal Hex. No. of Description Unit JBUS function
address address words available
51305 C869 1 phase power factor 1 -:
leading and + : lagging 0,001 3
51306 C86A 1 phase power factor 2 -:
leading and + : lagging 0,001 3
51307 C86B 1 phase power factor 3 -:
leading and + : lagging 0,001 3
51308 C86C 1 Reserved for manufacturer - 3
51309 C86D 1 Reserved for manufacturer - 3
51310 C86E 1 Reserved for manufacturer - 3
51311 C86F 1 Ea+ MWh 3
51312 C870 1 Reserved for manufacturer - 3
51313 C871 1 ER+ MWh 3
5 > TABLE C900Hex : Temperature measurements
Decimal Hex. No. of Description Unit JBUS function
address address words available
51456 C900 1 Internal temperature sensor present
0 : no - 1 : yes - 3
51457 C901 1 Temperature module °C 3
51458 C902 1
External temperature sensors (1 to 5max�
- 3
51459 C903 1 extern temperature 1 °C 3
51460 C904 1 extern temperature 2 °C 3
51461 C905 1 extern temperature 3 °C 3
51462 C906 1 extern temperature 4 °C 3
51463 C907 1 extern temperature 5 °C 3
6 > TABLE C950Hex : Harmonics
Decimal Hex. No. of Description Unit JBUS function
address address words available
THD
51536 C950 1 thd U12 0,001 3
51537 C951 1 thd U23 0,001 3
51538 C952 1 thd U31 0,001 3
51539 C953 1 thd V1 0,001 3
51540 C954 1 thd V2 0,001 3
51541 C955 1 thd V3 0,001 3
51542 C956 1 thd I1 0,001 3
51543 C957 1 thd I2 0,001 3
51544 C958 1 thd I3 0,001 3
51545 C959 1 thd In 0,001 3
Current
51546 C95A 1 Max rank 3
51547 C95B 1
Harmonic
I1 row 3 0,001 3
51548 C95C 1 Harmonic I2 row 3 0,001 3
51549 C95D 1 Harmonic I3 row 3 0,001 3
51550 C95E 1 Harmonic IN row 3 0,001 3
51551 C95F 1 Harmonic I1 row 5 0,001 3
51552 C960 1 Harmonic I2 row 5 0,001 3
51553 C961 1 Harmonic I3 row 5 0,001 3
51554 C962 1 Harmonic IN row 5 0,001 3
51555 C963 1 Harmonic I1 row 7 0,001 3
