DIRIS A40/A41 - RS485 - JBUS/MODBUS
®
GB
23
DIRIS A40/A41 - Ref.: 536 103 B GB
COMMUNICATION
LIST OF PARAMETERS TO BE DISPLAYED (FUNCTION 3)
Address available with the Monitoring or Control/Command option
Decimal Hexa. Number Text Unit
address address of words
866 362 2 Input pulse meter 1
868 364 2 Input pulse meter 2
870 366 2 Number of impulse meters
872 368 2 Current alarm :
0 : no alarm
1 : I
2 : U
3: ΣP+
4: ΣQ+
5: ΣS
6: F
7 : ΣPFL
8 : thd I
9 : thd U
10 : In
11 : HOUr
12 : V
13 : thd In
14 : thd V
15 : ΣP-
16 : ΣQ-
17 : Σ PFC
18 : T°C 1
19 : T°C 2
20 : T°C 3
21 : T°C internal
22 : T°C predicted
23 : T°C predicted
24 : T°C predicted
874 36A 2 Current overrun :
0 : no alarm
1 : I
2 : U
3: ΣP+
4: ΣQ+
5: ΣS
6: F
7 : ΣPFL
8 : thd I
9 : thd U
10 : In
11 : HOUr
12 : V
13 : thd In
14 : thd V
15 : ΣP-
16 : ΣQ-
17 : Σ PFC
18 : T°C 1
19 : T°C 2
20 : T°C 3
21 : T°C internal
22 : T°C predicted
23 : T°C predicted
24 : T°C predicted
876 36C 2 Number of inputs-outputs -
Low-order: number of inputs
High-order: number of outputs
