DIRIS A40/A41 - RS485 - JBUS/MODBUS
®
26
DIRIS A40/A41 - Ref.: 536 103 B GB
COMMUNICATION
LIST OF PARAMETERS TO BE DISPLAYED (FUNCTION 3)
1836 72C 1 Active energy + > 10000 kWh
1837 72D 1 Reactive energy + < 10000 kvarh
1838 72E 1 Reactive energy + > 10000 kvarh
1839 72F 1 Apparent energy < 10000 kVAh
1840 730 1 Apparent energy > 10000 kVAh
1841 731 1 Active energy - < 10000 kWh
1842 732 1 Active energy - >10000 kWh
1843 733 1 Reactive energy - < 10000 kvarh
1844 734 1 Reactive energy - > 10000 kvarh
1845 735 1 Input pulse meter 1 < 10000 –
1846 736 1 Input pulse meter 1 > 10000 –
1847 737 1 Input pulse meter 2 < 10000 –
1848 738 1 Input pulse meter 2 > 10000 –
1849 739 1 Input pulse meter 3 < 10000 –
1850 73A 1 Input pulse meter 3 > 10000 –
1851 73B 1 Input pulse meter 4 < 10000 –
1852 73C 1 Input pulse meter 4 > 10000 –
1853 73D 1 Input pulse meter 5 < 10000 –
1854 73E 1 Input pulse meter 5 > 10000 –
1855 73F 1 Input pulse meter 6 < 10000 –
1856 740 1 Input pulse meter 6 > 10000 –
1857 741 1 Average value of currents mA
1858 742 1 Average value of phase to phase voltages V/10
1859 743 1 Average
value of phase to neutral voltages
V/10
1860 744 1 avg U12 V/10
1861 745 1 avg U23 V/10
1862 746 1 avg U31 V/10
1863 747 1 avg V1 V/10
1864 748 1 avg V2 V/10
1865 749 1 avg V3 V/10
1866 74A 1 avg F Hz/100
1867 74B 1 max/avg U12 V/10
1868 74C 1 max/avg U23 V/10
1869 74D 1 max/avg U31 V/10
1870 74E 1 max/avg V1 V/10
1871 74F 1 max/avg V2 V/10
1872 750 1 max/avg V3 V/10
1873 751 1 max/avg F Hz/100
1874 752 1 thd I1 0.10%
1875 753 1 thd I2 0.10%
1876 754 1 thd I3 0.10%
1877 755 1 thd In 0.10%
1878 756 1 thd U12 0.10%
1879 757 1 thd U23 0.10%
1880 758 1 thd U31 0.10%
1881 759 1 thd V1 0.10%
1882 75A 1 thd V2 0.10%
1883 75B 1 thd V3 0.10%
Decimal Hexa. Number Text Unit
address address of words
