socomec STATYS series - Remote Control (System Access); Sensitivity Threshold (System Access); System Configuration (System Access); Timestamp (User Access)

15
STATYS 200-1000A - Ref.:OPMSTA200910-GB_06
ENGLISH
Timestamp (user access)
Display: day time
Date
Display: day
Default value: current day
Possible choice: day-month-year with day from 1 to 31, month from Jan to Dec and year from 00 to 99
Time
Display: time
Default value: actual hour
System conguration (System access)
Display: sys cfg
Password conguration
Display: pin code
User password
Display: usr pin (user pin)
Default value: _ _ _
Possible choice: 000 to 999 (000 = no password)
System password
Display: sys pin (system pin)
Default value: 000
Possible choice: 000 to 999
Remote control (System access)
Display: rem ctl (remote control)
Default value: en
Possible choice: en (enable) or dis (disable )
Sensitivity threshold* (System access)
Display: sen (sensitivity)
Default value: std
Possible choice: L for "low", std for "standard", H for "high" and cus for "custom" (conguration via PC link)
*Values used to carry out transfer (if authorised):
Low Sensitivity:
• the RMS voltage value exceeds the rated value by +/- 15%,
• The frequency exceeds the rated value by +/- 4 Hz,
• instantaneous voltage (1ms transient) drops to 40% below the RMS rated voltage.
High Sensitivity:
• the RMS voltage value exceeds the rated value by +/- 5%,
• The frequency exceeds the rated value by +/- 1 Hz,
• instantaneous voltage (1ms transient) drops to 15% below the RMS rated voltage.
Standard Sensitivity:
• the RMS voltage value exceeds the rated value by +/- 10%,
• The frequency exceeds the rated value by +/- 2 Hz,
• instantaneous voltage (1ms transient) drops to 25% below the RMS rated voltage.
7. mImIc paNEL
