7. 1.9. Test mode
This mode enables maintenance codes to be displayed in the form of pages marked with a number
For each maintenance page the following information appears:
– on the bottom line, the message "STS Code N° xxx" where xxx corresponds to the page n°,
– on the top two lines, 4 hexadecimal digits corresponding to the maintenance code.
the page is changed using the keys and
Pressing on the key launches a complete mimic panel test by:
– Switching on all LEDs,
– Displaying all LCD segments,
– Operating the buzzer.
This mode does not interrupt the normal operation of STATYS
7. 1.10. Programming mode
This mode is accessed by entering a password:
If the "user" password is inputted, only "user" parameters may be congured.
If the "system" password is inputted, all parameters could be modied.
Choice of preferred source (user access)
Display: PS
Default value: S1
Possible choice: S1 or S2
Modbus link conguration (user access)
Display: mod bus
Slave number
Display: sla nb
Default value: 1
Possible choice: 1 to 255
Link speed
Display: bds
Default value: 9600
Possible choice: 2400, 4800, 9600 or 19200
Link parity
Display: par
Default value: no
Possible choice: odd, eve (even) or no
