Sofar ME3000SP User Manual

38
7. Technical Data
Model
ME3000SP
Battery Parameters
Battery Type
Lead-acid, Lithium-ion
Nominal battery voltage
48V
Battery voltage range
42 - 58V
Recommended battery capacity
200Ah (100 – 500 Ah optional)
Recommended storage capacity
9.6 kWh
Max charge current
60A
Charge current range
0 – 60A programmable
Charge curve
3 - stage adaptive with maintenance
Max discharge current
65A
Battery protection
Over voltage protection / Over current protection /
Over temperature protection
Short circuit protection
100A fuse
Depth of discharge
Lithium: 0 – 80% DOD adjustable
Lead acid: 0 – 50% DOD adjustable
AC parameters
Max output power
3KVA single phase
Max output current
13A
Nominal grid voltage & frequency
230V, 47 – 53Hz or 57 – 63Hz
AC voltage range
150 – 275V (according to local authority requirements)
THDi
<3%
Power factor
1 (+ / - 0.8 adjustable)
Inrush current
0.8A / 1us
Max output fault current
100A / 1us
System parameters
Max efficiency
Charge: 94.1% / discharge 94.3%
Standby losses
< 5W
Topology
High frequency transformer isolated
Ingress protection ratings
IP 65
Safety protection
Anti-islanding, RCMU, ground fault monitoring
Communication
Wi-Fi, RS485

Sofar ME3000SP Specifications

General

Model	ME3000SP
Manufacturer	Sofar Solar
Type	Hybrid Inverter
Rated Power	3000 W
Max PV Input Voltage	500 V
Max PV Input Current	13 A
Battery Voltage Range	40-60 V
Efficiency	97.5%
Max. DC Voltage	500 V
Number of MPPTs	1
Max. Input Current per MPPT	13 A
Max. AC Power	3000 W
Max. AC Current	13.6 A
Rated AC Voltage	230 V
AC Voltage Range	180-280V
Rated Frequency	50/60 Hz
THDi	<3%
Euro Efficiency	97%
DC Switch	Yes
Protection Degree	IP65
Operating Temperature Range	-25°C to +60°C
Cooling	Natural Convection
Communication	RS485, WiFi (optional)
