Sofar ME3000SP User Manual

26
6.4 Menu
In the main interface, press “back” button to enter main menu. The main menu has the following five options:
Main Interface
Press “Back”
“Up” ↑
“Down”↓
1.Enter Setting
2.Event List
3.System Information
4.Software Update
5.Energy Statistic
6.4.1 Enter setting:
1.Enter Setting
Press “OK”
“Up” ↑
“Down”↓
1.Battery Parameter
8.Set Time
2.Clear Energy Data
9.Set EPS Mode
3.Clear Events
10. DRMs0 Control
4.Set Country
11. Auto Test (For Italian Market Only)
5.Set Communication Addr.
12. Work Mode Set
6.Function to Set Country
13. Safety Param. Settings
7.Set Language
1. Battery Parameter
1.Battery Parameter
1.Battery Type
7.Max. Discharge (A)
2*. Battery Capacity
8*. Low (V) Protection
3.Discharge Depth
9.Min. Discharge (V)
4.Max. Charge (A)
10*. Empty Discharged (V)
5.Over (V) Protection
11*. Full Charged (V)
6.Max Charge (V)
12.Save
Note: 2*/8*/10*/11* settings are only for DEFAULT battery type.
“Up” ↑
“Down”↓

Sofar ME3000SP Specifications

General

Model	ME3000SP
Manufacturer	Sofar Solar
Type	Hybrid Inverter
Rated Power	3000 W
Max PV Input Voltage	500 V
Max PV Input Current	13 A
Battery Voltage Range	40-60 V
Efficiency	97.5%
Max. DC Voltage	500 V
Number of MPPTs	1
Max. Input Current per MPPT	13 A
Max. AC Power	3000 W
Max. AC Current	13.6 A
Rated AC Voltage	230 V
AC Voltage Range	180-280V
Rated Frequency	50/60 Hz
THDi	<3%
Euro Efficiency	97%
DC Switch	Yes
Protection Degree	IP65
Operating Temperature Range	-25°C to +60°C
Cooling	Natural Convection
Communication	RS485, WiFi (optional)
