39
Environmental data
Ambient temperature range
-25C to +60C (derating above +45C)
Relative humidity range
0% - 100% (no condensing)
Protective class
Class I
Max operating altitude
2000m
Current transformer connection
Hard wired
General data
Noise
<25dB
Weight
16kg
Cooling
Natural convection
Dimensions (W*H*D)
532 x 360 x 173 mm
Display
LCD display
Warranty
5 years
EPS (Emergency Power Supply) data
EPS rated power
3000VA
EPS nominal voltage/frequency
230V, 50/60Hz
EPS rated current
13A
THDi
<3%
Switch time
< 3s

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Sofar ME3000SP and is the answer not in the manual?

Sofar ME3000SP Specifications

General IconGeneral
ModelME3000SP
ManufacturerSofar Solar
TypeHybrid Inverter
Rated Power3000 W
Max PV Input Voltage500 V
Max PV Input Current13 A
Battery Voltage Range40-60 V
Efficiency97.5%
Max. DC Voltage500 V
Number of MPPTs1
Max. Input Current per MPPT13 A
Max. AC Power3000 W
Max. AC Current13.6 A
Rated AC Voltage230 V
AC Voltage Range180-280V
Rated Frequency50/60 Hz
THDi<3%
Euro Efficiency97%
DC SwitchYes
Protection DegreeIP65
Operating Temperature Range-25°C to +60°C
CoolingNatural Convection
CommunicationRS485, WiFi (optional)
