PowerMagic 400V C&I Energy Storage System User Manual
Packing List, if there are any missing parts, please contact your dealer as soon as possible.
Step 5
Fix the energy storage system to the base or foundation.
⚫ When using a forklift truck to move the equipment, please tie down and secure it according to
the actual situation to ensure that there is no risk of the equipment tipping over.
⚫ When hoisting the energy storage system, it is necessary to ensure that the four corners of the
energy storage system coincide with the corners drawn on the concrete support platform.
⚫ There are four mounting holes at the contact between the Angle steel and the base, which
should be drawn when marking the mounting holes.
⚫ Each Angle steel shall ensure that there are two installation holes fixed. When drilling, two
installation holes on the outside shall be preferred. When the drilling drill interferes with the
reinforcement in the base concrete, the inner installation holes shall be selected.
⚫ When fixing the angle steel and the base, make sure that the expansion bolts are tightened.
Checklists
After the lifting of the energy storage system is completed, a post-installation inspection is
required to ensure normal use and smooth subsequent installation.
Table 4.4 Checks after installation
Are the bolts and nuts tight?
Use a spanner to
tighten again.
Bolts and nuts are tightened.
