Meters
Export Meter
RS485-1
Modbus ID #2
Status
Comm. Error
Power
7.60 kW
Energy
8.42 MWh
If the inline meter is not detected by Energy Net, "New Device" will not appear in
SetApp under "Device Manager" in the Commissioning page.
If a connectivity failure occurs, check the following:
If Energy Net is employed:
Make sure that an Energy Net module (see
Energy Net Support
on page 14) and
an external antenna are installed in the inverter.
If the inline meter is installed in a metal cabinet, or you suspect that there is a
range issue, an external antenna for the meter may be required (see the appendix
Supplemental Documentation
on page 43).
If RS485 wiring is used to connect the meter and the inverter, check that the wiring
is in accordance with the guidelines in
To wire the inverter's RS485 connection:
on
page 25
Check that the meter is configured as required in the chapter
"Configuration" on
page26
.
Check for water damage or sealing problems:
Inspect the entire conduit run for possible points of water penetration, and fix
leaks.
Ensure that proper outdoor rated components are used.
Use a Voltmeter to measure the voltage on the meter's AC wiring. The L1 – L2 – L3
line to line voltage should be 208-240 Vac.
The Energy value is not advancing
Make sure the correct meter function is selected.
Make sure that the AC Grid Connection is configured correctly.
Appendix A: Troubleshooting Meter Connection 37
Inline Energy Meter with SolarEdge Energy Net Communications
