S_OK:The connection to the monitoring platform. (Server Connected appears only
if the inverter is connected to the monitoring platform).
Status: The inverter operation status:Off, Not Paired, Night Mode, Error, Pairing, or
Production.
Switch: Indicates the position of the inverter ON/OFF/P switch: On, Off, or P
position.
CosPhi: Indicates the ratio between active and reactive power.A negative value
indicates a lagging CosPhi.
For more information, refer to the
Power Control Application
Note
, available on the SolarEdge website at
https://www.solaredge.com/sites/default/files/application_note_
power_control_configuration.pdf.
Limit: The inverter maximum output power
Country: The selected country and grid setting
Voltage (Vdc): The DC input voltage
Temp (°C or °F): The inverter heat sink temperature
Chapter 5: Activating, Commissioning and Configuring the System 41
EV Charging Single Phase Inverter Guide MAN-01-00583-1.5
