EV Charger and EV Charger Cable Specifications
NOTE
The EV Charger and EV Charger cable are ordered separately.
EV CHARGER
Charging Mode
AC Mode 3
Connection to the SolarEdge monitoring
platform is required for first EV charging
Minimum charge rate
(1)
1.5 kW
Rated AC Power Output
7400
W
Nominal AC Output Voltage 230 Vac
Nominal AC Frequency 50 / 60 Hz
Maximum Continuous Output
Current @230V
32 Aac
Residual Current Detector (AC) 30
mA rms
Residual Current Detector (DC) 6 mAdc
ADDITIONAL FEATURES
EV Charger Status LEDs, Fault
Indicator
Yes
EV Charger Ground Connection
Monitoring
Yes, continuous
EV Charger Configuration
Via the monitoring app; Ethernet, Wi-Fi or
ZigBee connection is required
(2)
EV Charger Unplugging
Detection
Yes, current termination according to IEC
62196
STANDARD COMPLIANCE
Safety IEC 61851, IEC 62752:2016
EVCharger IEC 62196
INSTALLATION SPECIFICATIONS
EV Charger Connector IEC 62196 Type 1 /Type 2
EV Charger Cable Length
(3)
7.6 (4.5 option) m
(1)
Minimum charge rate is in compliance with IEC61851-1 and J1772™ FEB2016 standards.
(2)
Cellular connection may be used; requires a SIM card with a 50MB data plan that should be purchased
from a cellular provider; a SolarEdge data plan supports activation only
(3)
EV Charger cable ordered separately.
Technical Specifications - EV Charging Single Phase Inverter (Europe & APAC)
85
EV Charging Single Phase Inverter Guide MAN-01-00583-1.5
