SolarEdge StorEdge Solution with Backup

Auto-Transformer Technical Specifications


 SEAUTO-TX-5000 
ELECTRICAL RATINGS  
Rated Power - Continuous 5000 VA
Rated Power - Peak 7600 for 10 sec VA
Output Voltage 120/ 240 Split Phase V
Max Continuous Output Current per Phase
@120V
25 A
Split Phase Imbalance (@ Rated Power)
Up to 25A difference
between phases

Thermal Protection Yes 
INSTALLATION SPECIFICATIONS  
AC Output conduit size / AWG range 0.75 / 14-10
in/ AWG
Dimensions (HxWxD) 6.7 x 7.9 x 5.5 / 170 x 200 x 140 in / mm
Weight 29.7 / 13.5 lb / kg
Min - Max Operating Temperature -13 to +140 / -25 to +60 °F / °C
Protection Rating NEMA 3R 
Installation Wall mounted 




StorEdge Solution with Backup MAN-01-00262-1.5
152 Auto-Transformer Technical Specifications
