SolarEdge StorEdge Solution with Backup User Manual

Error messages: In the event of a problem, an error message may be displayed on
the LCD panel.
For more information, refer to
https://www.solaredge.com/sites/default/files/troubleshooting_for_se_
inverter_insallation_guide_addendum_na.pdf and Inverter Configuration –
Setup Mode on page 72.
Inverter Configuration – Setup Mode
You can configure the inverter using one of the following:
The internal LCD user buttons. When using this option, the inverter cover is removed.
The external LCD light button. This option of configuration includes a less detailed set
of menus.
Configuring the Inverter Using the LCD User Buttons
After inverter installation, an installer may perform basic system configuration.
Configuration is done when the inverter is in Setup mode.
To enter Setup mode:
1.
Turn the inverter ON/OFF switch to OFF (AC remains ON).

WARNING!
If the inverter was operating properly (power was produced by the power
optimizers), the following message is displayed.
D C V O L T A G E N O T S A F E
D O N O T D I S C O N N E C T
V D C : 7 2 . 0
This message is displayed until the DC voltage is safe (50V). Do not open the
cover until the voltage is safe or until at least five minutes have passed.
 AVERTISSEMENT!

La tension de sécurité par défault est de 50V.
Ne pas ouvrir le couvercle ou les connecteurs DC jusqu'à ce que la tension
soit affichée comme sécurisé ou jusqu'à ce que cinq minutes au moins se
soient écoulées.
2. Press the Enter button for at least 5 seconds. The following message is displayed:
P l e a s e e n t e r
 P a s s w o r d
* * * * * * * *
StorEdge Solution with Backup MAN-01-00262-1.5
72 Inverter Configuration – Setup Mode
