Status Screens - Operational Mode
Additional presses display the following screens one after the other.
Initial Status
V a c [ V ] V d c [ V ] P a c [ W ]
2 4 0 . 7 3 7 1 . 9 2 3 4 9 . 3
P _ O K : X X X / Y Y Y < S _ O K >
O N
Vac [V]: The AC output voltage
Vdc [V]: The DC input voltage
Pac [W]: The AC output power
Main Inverter Status
V a c [ V ] V d c [ V ] P a c [ W ]
2 4 0 . 7 3 7 1 . 9 3 2 1 0 . 0
F a c [ H z ] O P s _ O k T e m p
5 0 . 0 1 1 2 8 . 2
Vac [V]: The AC output voltage.
Vdc [V]: The DC input voltage.
Pac [W]: The AC output power.
Fac [Hz]: The AC output frequency.
OPs_Ok: Number of optimizers sending telemetries (indicating that they are paired)
Temp [C or F]: The inverter heat sink temperature
Energy Meter Status
Displays the total energy produced during the last day, month, year and since inverter
installation.
D a y [ W h ] : 0 . 0
M o n t h [ K W h ] : 0 . 0
Y e a r [ K W h ] : 0 . 0
T o t a l [ K W h ] : 0 . 0
Day: since midnight
Month: since 1st of the current month until today (inclusive)
Year: since January 1st until today (inclusive)
StorEdge Solution with Backup MAN-01-00262-1.5
86 Status Screens - Operational Mode
