Server: The method of connection to the SolarEdge monitoring platform.
S_OK: The connection to the SolarEdge monitoring platform is successful (should
appear only if the inverter is connected to the server).
Status: Displays OK if the inverter established successful connection and
communication with the specified server port/device (LAN, RS485 or ZigBee Plug-
in).
xxxxxxxx: Eight-bit Ethernet communication connection status: A string of 1s and
0s is displayed. 1 indicates OK, 0 indicates an error. For a list of the possible errors
and how to troubleshoot them, refer to Troubleshooting on page 123. For a list of
the possible errors and how to troubleshoot them, refer to Errors and
Troubleshooting on page 1.
Error message, according to failure. Refer to .
IP Status
This screen describes the Ethernet configuration: IP, Mask, Gateway and MAC address
(Media Access Control) of the Inverter.
I P 1 9 2 . 1 6 8 . 2 . 1 1 9
M S K 2 5 5 . 2 5 5 . 2 5 5 . 0
G W 1 9 2 . 1 6 8 . 2 . 1
M A C 0 - 2 7 - 0 2 - 0 0 - 3 9 - 3 6
ZigBee Status
This screen describes the ZigBee configuration:
P A N : X X X X X
C H : X X / X X X X R S S I : < L >
M I D : X X X X X X
RSSI: The receive signal strength indication of the closest ZigBee in the system. L =
low, M = medium, H = high and (-) = no signal.
PAN ID: The ZigBee transceiver PAN ID (Personal Area Network Identification), the
IDuniquely represents a device in a Zigbee network.
Ch.: The ZigBee transceiver channel
ID: The ZigBee transceiver ID
