Measured value Description Unit
Current Iac L1 AC output current, phase 1 A
Current Iac L2 AC output current, phase 2 A
Current Iac L3 AC output current, phase 3 mA
Current Iac mean DC proportion in mains current A
Current Idc DC input current A
Current Idc1… Fehlerstrom gegen Erde mA
Current Idc12 DC input current tracker 1 … tracker 12 mA
Current Ierr gnd Leakage current to ground mA
Current Ierr_ac AC proportion in leakage current to ground mA
Current Ierr_dc DC proportion in leakage current to ground V
Current Ierr_eff Effective value of AC proportion in leakage current to
ground
V
Chained voltage L1 – L2 Voltage between the L1 and L2 outside conductors V
Chained voltage L1 – L3 Voltage between the L1 and L3 outside conductors °C
Chained voltage L2 – L3 Voltage between the L2 and L3 outside conductors
Temp. power unit 1 Temperature of the power unit 1 A
Cosphi Power factor W / m2
String 1 … string 16 String current 1 … string current 16 (MaxConnect+) kWh / m2
Insolation Solar irradiation (MaxMeteo) °C
Insolation energy day Irradiation energy of the current day (MaxMeteo) °C
Ambient temp. 1 Ambient temperature 1 (MaxMeteo) °C
Ambient temp. 1 Ambient temperature 2 (MaxMeteo) kWh
Cell temp. Solar cell temperature (MaxMeteo) kWh
Energy counter A day Daily yield current counter 1 (MaxCount) kWh
Energy counter A total Total yield current counter 1 (MaxCount) kWh
Energy counter A year Annual yield current counter 1 (MaxCount) kWh
Energy counter B day Daily yield current counter 2 (MaxCount) kWh
Energy counter B total Total yield current counter 2 (MaxCount) kWh
Energy counter B year Annual yield current counter 2 (MaxCount) kWh
Click on the Next button to continue the wizard.
