SolarMax MaxWeb XPN - Page 66

66
Front, terminals
at the top
Front, terminals
at the bottom
1 6 1 6
1 6 1 6
Analog Inputs
up Block 1
down Block 2
S0-Pulse
Block 3
CAN-Bus
Block 4
Fig. 65: Terminal assignment on the front of the MaxWeb XPN
Front of the MaxWeb XPN, terminals at the top
1
Analogue measurement inputs
S0 pulses
A3
GND
A4
GND
V+
free
S0_B
-
S0_B+
free
S0_A
-
S0_A+
free
2
3
4
5
6
1
2
3
4
5
6
