7828 Density Transmitter Technical Manual Introduction
78285000_AB 4-5
4.4 USING ADVIEW
4.4.1 ADVIEW FACILITIES
The main ADView window gives access to the various facilities available. A brief
description of each is listed below. Using the facilities is largely intuitive, and hands-on
experience is probably the best way to learn about the system.
Communications
Sets up and checks RS232/485 communications (see section
4.3.1)
Board Configuration
(See section 4.4.4.) Enables you to select the measured
parameter and range for the analog output, and to configure
density referral by entering matrix values or K factors, as well as
special calculations, line pressure and averaging time.
Displays instantaneous values of a selectable output parameter
and the analog output.
Data logging
(See section Error! Reference source not found..) Provides
tabular data from transmitters of line and base density,
temperature and special function. One parameter can be
displayed as a graph.
Data can also be logged to a file in either Excel (tab delimited) or
Notepad (space delimited) formats.
The frequency at which results are logged can be set, and logging
can be started and stopped.
Diagnostics
Enables you to view:
- live sensor readings
- the status of the meter
- values of working coefficients
You can also verify calculations.
Transducer details
Shows a list of details such as type, serial number, calibration
dates, software version, etc.
Register dump/load
With this facility you can dump the contents of all (or selected)
Modbus registers from the device, or alternatively transmit values
to them. File format is selectable (Excel/tab delimited, or
Notepad/Space delimited).
Use this to quit from ADView.
