Introduction 7828 Density Transmitter Technical Manual
4-6 78285000_AB
4.4.2 MENU BAR
File
Exit Another way of quitting ADView
Tools
Health Check Determines whether the system is functioning
correctly
Register Read/Write A facility for reading or writing to any of the
Modbus registers (see section 4.4.7)
Direct Comms Enables you to specify exactly what will be
transmitted on the Serial link (see Appendix D).
Engineer Status Only used by Solartron service engineers
Options
Simulate board
response/
Actual Board
Allows you to select between these two options
Enable / disable
screensaver
Allows you to select between these two options.
When enabled, the screensaver operates as
configured by the Windows system settings.
Window
Provides a means of opening or selecting
ADView’s facilities.
Help
Help on ADView Limited help text, best read when first using
ADView.
About ADView Displays software version number.
4.4.3 CONFIGURING A SLAVE ADDRESS
The 7828 factory configuration sets the slave address to 1. However, in many
applications it will be necessary to allocate another address. In a multi-drop application,
where several Modbus devices are connected on the same network, it is essential to
configure unique slave addresses for each device.
To do this, you will need to run ADView and use the Register Read/Write facility, detailed
in section 4.4.7. Check the value in Register 30 (Modbus Slave Address). If it is not the
required value, enter the desired value and click on the write button. The 7828 will now be
configured with the new slave address.
