System Options
• TR and Automation Total Recall and mix automation are system options available at additional cost. They are
n
ormally specified at time of order but can also be installed subsequently.
• Speaker shelves A flat shelf that fits over the top trim of the console. Can be retrofitted to existing consoles
w
ithout modification.
• Additional patchrows 1U connectorised 2 x 48-jack patchrows. Can be specified independently from patchbays.
Mating D25–D25 cables are not supplied. DL socket to 3-off 25-way D-type-male adaptor
leads are available at extra cost.
• DL Connector Panel The internal patchbay option is wired out as standard to a panel fitted with D25 female
connectors. This panel can be replaced with one fitted with DL96 female connectors to
simplify the interface to an installation where DL connectors are already in use.
• TFT Monitor arm A vertical adjustable arm fitted to the rear of the console to which one or two LCD
monitors may be mounted. Suitable for monitors equipped with the VESA MIS-D 100
mounting.
• LCD Phasescope The DK Audio MSD600M or the RTW10830 phasescope may be optionally mounted
above the top trim using a bracket (supplied). Connection is to the dedicated ‘Meter Out’
socket at the rear of the console; a mating cable loom is also supplied.
• PSU redundancy For critical operations, such as live recording or on-air production, a dual power supply
system can be specified. This option features two independent PSUs per console section,
each having an independent mains supply input connector.
• Script Tray A 315mm wide Perspex panel which fits over the channel area leaving the faders free. The
tray is fitted with rollers allowing it to be moved sideways across the console.
Page 9
Duality SE Installation Guide
Section 3 Pre Installation Information
