Solid State Logic Duality SE Installation Guide

Appendix A – Specifications
Page 42
Duality SE Installation Guide
A – Specifications Appendices
Duality Console
Parameter Condition Value Unit Notes
Height To top of meter trim 982 mm
H
eight adjustment
-
0 +10
m
m
Width: 24 channel console 1,620 mm No patchbay
(1) 48 channel console 2,610 mm No patchbay
48 channel console plus patch 3,098 mm Internal patchbay
72 channel console 3,600 mm No patchbay
96 channel console 4,590 mm No patchbay
19” racking section 488 mm
Producer’s table section 603 mm
Depth 1,024 mm
Weight: 24ch 180 Kg
48ch 300 Kg
72ch 420 Kg
96ch 540 Kg
19” patch section 15 Kg Empty
1U patchrow 3.2 Kg Each
Producer’s section 18 Kg
Heat dissipation: 24ch 880 W
48ch 1,540 W
72ch 2,200 W
96ch 2,860 W
Voltage Input range 100 – 240 V ±10%
Current: Over voltage range, 24ch 9.1 – 3.9 A
Over voltage range, 48ch 16.0 – 6.7 A
Over voltage range, 72ch 22.9 – 9.6 A
Over voltage range, 96ch 29.8 – 12.5 A
Power factor 0.95
Fusing None
Noise Fanless
Connectors: Mains input IEC male
MIDI 5-pin DIN 180° female
Network RJ45 100BaseT
Line level audio 25-way D-type female
Microphone input XLR 3-pin female
Mini LS output XLR 3-pin male
TB / Listen Mic / FB sends 1/4” TRS jack female
USB 4-pin type A
Serial 9-way D-type female
Appendices
1. Dimensions apply to straight consoles only. For dimensions of angled consoles, refer to SSL’s Project Engineering
Department.

Solid State Logic Duality SE Specifications

General

Brand	Solid State Logic
Model	Duality SE
Category	Music Mixer
Language	English
