Page 45
Duality Installation Guide
Appendices C – Connector Pinouts
Centre Section Connectors
Ext A 1–4 / Meter Out / Ext B In / Monitor Insert
Location: Center section rear panel – upper
C
onnector Type: 25-way D-type female
Cct Hot Cold Screen
Ext A (1–4) Meter Out Ext B input Mon Ins Send Mon Ins Ret
1 24 12 25 Left Left 1 Left Left Left
2 10 23 11 Right Right 1 Right Right Right
3 21 9 22 Centre Centre 2 Left Centre Centre
4 7 20 8 LFE LFE 2 Right LFE LFE
5 18 6 19 Surr’ Left Surr’ Left 3 Left Surr’ Left Surr’ Left
6 4 17 5 Surr’ Right Surr’ Right 3 Right Surr’ Right Surr’ Right
7 15 3 16 – Solo Left 4 Left Lt to Decoder Lt from Enc
8 1 14 2 – Solo Right 4 Right Rt to Decoder Rt from Enc
Monitor Outputs A & B / Track Sends / Cue-FX
Location: Center section Rear Panel – Upper L
Connector Type: 25-way D-type female
Cct Hot Cold Screen
Mon A Mon B Track Sends Cue/FX Send
1 24 12 25 Main Left Alt Left 1 (9, 17) Cue A Left
2 10 23 11 Main Right Alt Right 2 (10, 18) Cue A Right
3 21 9 22 Main Centre Alt Centre 3 (11, 19) Cue B Left
4 7 20 8 Main LFE Alt LFE 4 (12, 20) Cue B Right
5 18 6 19 Main Surr’ Left Alt Surr’ Left 5 (13, 21) FX 1
6 4 17 5 Main Surr’ Right Alt Surr’ Right 6 (14, 22) FX 2
7 15 3 16 Mini A Left Mini B Left 7 (15, 23) FX 3
8 1 14 2 Mini A Right Mini B Right 8 (16, 24) FX 4
Echo returns 1–4 / Mix Insert / Main Mix Outputs
Location: Center section Rear Panel – Lower
Connector Type: 25-way D-type female
Cct Hot Cold Screen
Echo Returns Mix Insert Send Mix Insert Rtn Main Mix Out
1 24 12 25 1 Left Left (AL) Left (AL) Left (AL)
2 10 23 11 1 Right Right (AR) Right (AR) Right (AR)
3 21 9 22 2 Left Centre (BL) Centre (BL) Centre (BL)
4 7 20 8 2 Right LFE (BR) LFE (BR) LFE (BR)
5 18 6 19 3 Left Surr’ Left (CL) Surr’ Left (CL) Surr’ Left (CL)
6 4 17 5 3 Right Surr’ Right (CR) Surr’ Right (CR) Surr’ Right (CR)
7 15 3 16 4 Left Stereo Left Stereo Left Stereo Left
8 1 14 2 4 Right Stereo Right Stereo Right Stereo Right
