Solid State Logic Duality SE Installation Guide

Page 44
Duality Installation Guide
C – Connector Pinouts Appendices
Appendix C – Connector Pinouts
Channel Bay Connectors
Duality Installation Guide
Channel Outputs / Key / Insert Send & Return / Monitor Input
L
ocation: 24 Channel Bay Rear Panel
Connector Type: 25-way D-type female
Pin Description Notes
1 cct 8 +
14 cct 8 –
2 cct 8 Screen
15 cct 7 +
3 cct 7 –
16 cct 7 Screen
4 cct 6 +
17 cct 6 –
5 cct 6 Screen
18 cct 5 +
6 cct 5 –
19 cct 5 Screen
7 cct 4 +
20 cct 4 –
8 cct 4 Screen
21 cct 3 +
9 cct 3 –
22 cct 3 Screen
10 cct 2 +
23 cct 2 –
11 cct 2 Screen
24 cct 1 +
12 cct 1 –
25 cct 1 Screen
13 n/c
Channel Input
Location: 24 Channel Bay Rear Panel
Connector Type: XLR 3-pin female
Pin Description Notes:
1 Ground
2 Hot (+ve)
3 Cold (-ve)
