Solid State Logic Duality SE Installation Guide

Page 43
Duality SE Installation Guide
Appendices B – Connector Details
Appendix B – Connector Details
Connectors Viewed From Wiring Side
1
2
3
4
5
14
15
16
17
6
7
8
9
10
18
19
20
21
11
12
13
22
23
24
25
1
2
3
4
5
14
15
16
17
6
7
8
9
10
18
19
20
21
11
12
13
22
23
24
25
D-Type Multipin
25-way
Dimensions: 55 x 15mm (approx.)
Cable Dia: 8mm (typical)
Plug
Socket
1/4” TRS Jack
Pinout for balanced audio:
Tip Hot (+ve)
Ring Cold (-ve)
Sleeve Screen
Stereo Plug
Connectors Viewed From Wiring Side
Plug
Socket
1
2
3
1
2
3
XLR 3-Pin
Dimensions: 19 x 60mm (approx.)
Cable Dia: 5 – 12mm (typical)
Pinout for balanced audio:
Pin 1 Screen/Ground
Pin 2 Hot (+ve)
Pin 3 Cold (-ve)
Connectors Viewed
From Wiring Side
Plug–Plug
MIDI Lead
Plug
Socket
2
5
3
4
1
2
5
3
4
1
DIN 5-Pin 180°
Dimensions: 15mm dia.
Cable Dia: 4mm - 7mm (typical)
Pinout as used for MIDI signals:
Pin 1 n/c
Pin 2 Screen
Pin 3 n/c
Pin 4 Midi +
Pin 5 Midi -
1
2
4
5
3
1
2
4
5
3
Tip
(T)
Ring
(R)
Sleeve
(S)
