1. Prerequisite information 15
1. 1. Area of application 15
1. 2. Liability 15
2. Installation 16
2. 1. Installation 16
2. 2. Wiring 17
2. 3. Commissioning 18
2. 4. Tips and recommendations for installation 19
3. Use and maintenance 20
3. 1. Raising and lowering the roller shutter 20
3. 2. Obstacle detection 20
3. 3. Anti-freeze protection 20
4. Tips and recommendations for use 21
5. Technical data 21
The ilmo 50 WT is a non-adjustable motor: a simple connection is all that is required.
The ilmo 50 WT programs its end limits automatically.
The ilmo 50 WT can be mounted either on the right or the le-. It can be controlled from a control point with a
fixed position or momentary action-type switch.
The ilmo 50 WT is equipped with:
- obstacle protection to protect the roller shutter when it is being lowered.
- anti-freeze protection to protect the roller shutter when it is being raised.
CONTENTS
ORIGINAL GUIDE
These instructions apply to all ilmo50WT drives, the different versions of which are available in the
current catalogue.
1. PREREQUISITE INFORMATION
1. 1. AREA OF APPLICATION
The ilmo 50 drive is designed to drive all types of roller shutters equipped with rigid links and
stops.
The professional motorisation and home automation installer must ensure that, once installed, the installation
of the motorised product complies with the standards in force in the country in which it is commissioned such
as, for example, the EN13659 roller shutters standard.
1. 2. LIABILITY
Please read these instructions carefully before installing and using the drive. In addition to following the
instructions given in this guide, the instructions detailed in the attached Safety instructions document
must also be observed.
The drive must be installed by a motorisation and home automation professional, according
to instructions from Somfy and the regulations applicable in the country in which it is
commissioned.
It is prohibited to use the drive outside the field of application described above. Such use, and any failure to
comply with the instructions given in this guide and in the attached Safety instructions document, absolves
Somfy of any liability and invalidates the warranty.
The installer must inform its customers of the operating and maintenance conditions for the drive and must
provide them with the instructions for use and maintenance, and the attached
Safety instructions document,
a-er installing the drive. Any A-er-Sales Service operation on the drive must be performed by a motorisation
and home automation professional.
If in doubt when installing the drive, or to obtain additional information, contact a Somfy adviser or go to the
website www.somfy.com.
Safety warning!
1
Caution! Information
