Network
Test: Ping
Network (Network Test Diagnostics Screen: Ifconfig)
Overview:
This is the network menu.
The various network diagnostic functions are accessed from this menu.
Screen 1: Ifconfig test
Operations:
[ENT] Execute the Ifconfig command (Display network settings)
[RIGHT] Open the Ping test
[RTN] Return to Service Mode top menu
Screen 2: Ping test
Operations:
[LEFT] Open the Ifconfig test
[RTN] Return to Service Mode top menu
For details on the Ping test, refer to the next page.
Screen 3: During execution of Ifconfig test
The Ifconfig command output results are displayed.
Operations:
[ENT] Execute again
[RIGHT] Open the Ping test
[RTN] Return to Service Mode top menu
Display panel:
S-NET
(Screen 2)
Network
Test: Ifconfig
ޓޓ
Ping To :
[START]
Ping To :
Ping
Ifconfig
(Screen 3)
Network
Test: Ping
Link encap:Ethernet HWaddr 00:16:01:85:21:A3
inet addr:43.17.110.225 Bcast:43.17.110.255 Mask:255.255.255.0
inet6 addr: fe80::216:1ff:fe85:21a3/64 Scope:Link
UP BROADCAST RUNNING MULTICAST MTU:1500 Metric:1
RX packets:533280 errors:0 dropped:0 overruns:0 frame:0
TX packets:219639 errors:0 dropped:0 overruns:0 carrier:0
collisions:0 txqueuelen:1000
RX bytes:44569483 (42.5 MiB) TX bytes:46206300 (44.0 MiB)
Interrupt:217 Base address:0x9c00
HELP: [ENT]:Re/Exe [RIGHT]
Ifconfig
The actual screens may differ slightly from the screen content shown here.
