Network (Network Test Diagnostics Screen: Ping)
Overview:
Ping test
Screen 1: Ping test
Operations:
[UP] Set the IP address of the ping location
[DOWN] Prepare to execute test
[RTN] Return to Service Mode top menu
For details on the Ping test, refer to the next page.
Screen 2: Specify the IP address of the ping location (IP input mode)
When “Ping To:” is highlighted, press [ENT] to enter the IP address.
Operations:
[ENT] Exit input
[RTN] Exit input
[LEFT] Exit input, and open the Ifconfig test
[(NUM)] Enter numbers from 0 to 9
[TIME] Enter the character “.”
[CLEAR] Backspace
Screen 3: During execution of Ping test
When “START” is highlighted, pressing [ENT] executes the Ping test.
Operations:
[ENT] Execute Ping test
[UP] Set the IP address of ping location
[DOWN] Prepare to execute test
[RTN] Return to Service Mode top menu
Display panel:
S-NET
(Screen 1)
Network
Test: Ifconfig
ޓޓ
Ping To :
[START]
Ping To :
Ping
(Screen 2)
Network
Test: Ifconfig
ޓޓ
[ENT] : Release
[RET] : Release
[LEFT] : Ifconfig Test
[(NUM)]: ‘0-9’
[TIME] : ‘.’
[CLEAR]: Backspace
Ping To :> 172.16.200.13
Ping
(Screen 3)
Network
Test: Ifconfig
ޓޓ
Ping To : 172.16.200.13
PING 172.16.200.13 (172.16.200.13) 56(84) bytes of data.
64 bytes from 172.16.200.13: icmp_seq=0 ttl=64 time=0.022 ms
--- 172.16.200.13 ping statistics ---
1 packets transmitted, 1 received, 0% packet loss, time 0ms
rtt min/avg/max/mdev = 0.022/0.022/0.022/0.000 ms, pipe 2
[HELP]: [ENT]:Start [UP][LEFT]
Ping
The actual screens may differ slightly from the screen content shown here.
[START]
To Next Page
