Working Instruction Repair Instruction Mechanical/
1275-8436 Rev2
© Sony Mobile Communications AB – Company Internal
10(50)
Disassembly
Remove the Rear Cover Assy.
Battery FPC Mylar is folded under Battery FPC at shown
area.
Turn around the Battery FPC Mylar with Battery FPC from
Main PBA.
Turn around the folded Battery Mylar FPC from Battery FPC.
To Next Page
