Sony C2305 - Camera Module CMOS 0.3 M

Working Instruction Repair Instruction Mechanical/
1275-8436 Rev2
© Sony Mobile Communications AB – Company Internal
21(50)
Replacement
4.11 Camera Module CMOS 0.3M
Follow the 3.1 – 3.4 Disassembly instructions!
Carry out the Removal as described below.
Prepare a new Camera Module CMOS 0.3M.
Carry out the Installation as described below.
Follow the 5.1 – 5.4 Reassembly instructions!
REMOVAL
Remove the Camera Module CMOS 0.3M.
INSTALLATION
Place a new Camera Module CMOS 0.3M in the correct
position as shown in the picture.
Be careful, do not damage Camera Module CMOS 0.3M!
