Working Instruction Repair Instruction Mechanical/
1275-8436 Rev2
© Sony Mobile Communications AB – Company Internal
2(50)
CONTENTS
1 Exterior Views ................................................................................. 4
1.1 C2305, S39h ........................................................................................... 4
2 Tools ................................................................................................ 5
3 Disassembly.................................................................................... 6
3.1 Battery Cover Assy ............................................................................... 6
3.2 Rear Cover Assy .................................................................................... 7
3.3 Main PBA (a) & Coaxial Cable (b) ...................................................... 13
3.4 Front Cover LCM TP Assy .................................................................. 15
4 Replacement ................................................................................. 16
4.1 Battery Cover Assy ............................................................................. 16
4.2 Rear Cover Assy .................................................................................. 16
4.3 Screw TORX 1.6mm 2.8mm Black ..................................................... 16
4.4 Screw TORX 1.6mm 4.5mm Black ..................................................... 16
4.5 Front Cover LCM TP Assy .................................................................. 17
4.6 LCM ZIF MYLAR .................................................................................. 17
4.7 TP FPC MYLAR .................................................................................... 17
4.8 Battery 2330.0 mA & Embedded Battery Adhesive .......................... 18
4.9 Battery FPC Mylar ............................................................................... 20
4.10 Core Unit Label .................................................................................... 20
4.11 Camera Module CMOS 0.3M ............................................................... 21
4.12 Film RF hole ......................................................................................... 22
4.13 Conductive WIFI Grounding Gasket .................................................. 23
4.14 Loudspeaker & Speaker Adhesive .................................................... 24
4.15 Camera Module CMOS 8M .................................................................. 26
4.16 Link FPC ............................................................................................... 28
4.17 Receiver & Receiver Adhesive ........................................................... 29
4.18 Coaxial Cable ....................................................................................... 31
4.19 SUB Board Assy & Sub PBA Adhesive ............................................. 32
4.20 Liquid Intrusion Label ......................................................................... 34
4.21 SIM Board Assy &RF Shielding Cover &SIM conductive adhesive 36
4.22 Board Swap – Replacement .............................................................. 38
4.23 Board Swap – Change Label .............................................................. 38
4.24 Board Swap – Customize of Software ............................................... 38
5 Reassembly................................................................................... 39
5.1 Front Cover LCM TP Assembly .......................................................... 39
5.2 Main PBA (a) & Coaxial Cable (b) ...................................................... 40
5.3 Rear Cover Assy .................................................................................. 45
5.4 Battery Cover Assy ............................................................................. 47
