Working Instruction Repair Instruction Mechanical/
1275-8436 Rev2
© Sony Mobile Communications AB – Company Internal
15(50)
Disassembly
Open the other side hook of Main PBA.
Remove the Main PBA and Coaxial Cable.
3.4 Front Cover LCM TP Assy
Front Cover LCM TP Assy as shown in picture.
