Working Instruction Repair Instruction Mechanical/
1275-8436 Rev2
© Sony Mobile Communications AB – Company Internal
14(50)
Disassembly
Open the Touch Panel ZIF connector.
Pull out the Touch Panel FPC.
Turn around the Touch Panel FPC from Main PBA.
Open the Main PBA hook using Front Opening Tool.
To Next Page
