Sony C2305 - Replacement; Battery Cover Assy; Rear Cover Assy; Screw TORX 1.6 Mm 2.8 Mm Black

Working Instruction Repair Instruction Mechanical/
1275-8436 Rev2
© Sony Mobile Communications AB – Company Internal
16(50)
4 Replacement
4.1 Battery Cover Assy
Follow the 3.1 Disassembly instructions!
Prepare a new Battery Cover Assy.
Follow the 5.4 Reassembly instructions!
4.2 Rear Cover Assy
Follow the 3.1 – 3.2 Disassembly instructions!
Follow the 4.12 Removal instructions!
Prepare a new Rear Cover Assy.
Follow the 4.12, 4.8 Installation instructions!
Follow the 5.3 -- 5.4 Reassembly instructions!
4.3 Screw TORX 1.6mm
2.8mm Black
Follow the 3.1 – 3.2 Disassembly instructions!
Prepare new Screws.
Follow the 5.3 – 5.4 Reassembly instructions!
4.4 Screw TORX 1.6mm
4.5mm Black
Follow the 3.1 – 3.2 Disassembly instructions!
Prepare new Screws.
Follow the 5.3 – 5.4 Reassembly instructions!
