Working Instruction Repair Instruction Mechanical/
1275-8436 Rev2
© Sony Mobile Communications AB – Company Internal
38(50)
Replacement
4.22 Board Swap – Replacement
Follow the 3.1 – 3.4 Disassembly instructions!
Follow the 4.16, 4.13, 4.19, 4.11, 4.18, 4.21 Removal
instructions!
Replace the Swap Board.
Follow the 4.16, 4.13, 4.19, 4.11, 4.18, 4.21 Installation
instructions!
Follow the 5.1 – 5.4 Reassembly instructions!
Note: Calibrate the Proximity sensor/Light sensor 1277-
0611 Trouble Shooting Application – mechanical after
replacement.
4.23 Board Swap – Change Label
CHANGE LABEL
Follow the instructions in the Generic Repair Manual –
Build swap for change of label.
4.24 Board Swap – Customize of Software
CUSTOMIZE OF SOFTWARE
Follow the instructions in the Generic Repair Manual –
Build swap for customization of the software.
