Working Instruction Repair Instruction Mechanical/
1275-8436 Rev2
© Sony Mobile Communications AB – Company Internal
37(50)
Replacement
Place a new SIM conductive adhesive on RF Shielding
Cover.
Place a new SIM Board Assy on Main PBA.
Assemble SIM PCB with 4 Alignments on Shielding Can.
Press BtB connector area on SIM Board Assy to secure it
well assembled on Main PBA.
To Next Page
