Working Instruction Repair Instruction Mechanical/
1275-8436 Rev2
© Sony Mobile Communications AB – Company Internal
46(50)
Reassembly
Check the speaker and Metal shielding are well in position
on Rear Cover Assy.
There are 10 hooks around Front Cover LCM TP Assy.
Assemble Rear Cover Assy on Core Unit.
Press all four sides around Rear Cover Assy securing all
hooks.
To Next Page
