Sony CCD-TR315E - Page 166

6-23
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
SE-80/81
< CONNECTOR >
* CN101 1-764-521-11 CONNECTOR, FFC/FPC (ZIF) 12P
< DIODE >
D102 8-719-062-16 DIODE 01ZA8.2(TPL3)
D103 8-719-062-16 DIODE 01ZA8.2(TPL3)
< JACK >
J101 1-537-747-41 TERMINAL BOARD (VIDEO/AUDIO)
< COIL >
L101 1-414-072-11 INDUCTOR 1uH
L102 1-216-295-91 SHORT 0
(TR315E/TR516E/TRV16E/TRV27EP/TRV46E:E,HK,AUS,CN)
L102 1-412-963-11 INDUCTOR 100uH
(TR415E/TR425E/TR515E/TR713E/TRV26E/TRV27E/TRV36E/
TRV46E:AEP,UK,EE,NE,RU)
< TRANSISTOR >
Q101 8-729-101-07 TRANSISTOR 2SB798-T1-DLDK
Q102 8-729-230-63 TRANSISTOR 2SD1819A-QRS-TX
< RESISTOR >
R101 1-216-864-11 METAL CHIP 0 5% 1/16W
R102 1-216-138-00 METAL CHIP 3.3 5% 1/8W
R103 1-216-830-11 METAL CHIP 5.6K 5% 1/16W
R104 1-216-820-11 METAL CHIP 820 5% 1/16W
R105 1-216-836-11 METAL CHIP 18K 5% 1/16W
R109 1-216-821-11 METAL CHIP 1K 5% 1/16W
A-7073-789-A SE-80(MM) BOARD, COMPLETE (TR713E)
*************************
(Ref. No. 4,000 Series)
A-7073-803-A SE-81(VMMCE) BOARD, COMPLETE
****************************
(TRV46E:AEP,UK,EE,NE,RU)
A-7073-810-A SE-81(VMM) BOARD, COMPLETE
**************************
(TRV46E:E,HK,AUS,CN)
A-7073-825-A SE-81(V) BOARD, COMPLETE
************************
(TRV16E/TRV27EP)
A-7073-849-A SE-81(VCE) BOARD, COMPLETE
**************************
(TRV26E/TRV27E/TRV36E)
(Ref. No. 9,000 Series)
< CAPACITOR >
C451 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
(TR713E/TRV46E)
C452 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
(TR713E/TRV46E)
C453 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
(TR713E/TRV46E)
C454 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
(TR713E/TRV46E)
C457 1-164-343-11 CERAMIC CHIP 0.056uF 10% 25V
(TR713E/TRV46E)
C458 1-164-343-11 CERAMIC CHIP 0.056uF 10% 25V
(TR713E/TRV46E)
C459 1-164-343-11 CERAMIC CHIP 0.056uF 10% 25V
(TR713E/TRV46E)
C460 1-110-666-11 ELECT CHIP 22uF 20% 6.3V
(TR713E/TRV46E)
C461 1-164-343-11 CERAMIC CHIP 0.056uF 10% 25V
(TR713E/TRV46E)
C462 1-110-666-11 ELECT CHIP 22uF 20% 6.3V
(TR713E/TRV46E)
C464 1-110-501-11 CERAMIC CHIP 0.33uF 10% 16V
(TR713E/TRV46E)
C465 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
(TR713E/TRV46E)
C466 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(TR713E/TRV46E)
C467 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(TRV26E/TRV27E/TRV36E/TRV46E:AEP,UK,EE,NE,RU)
C468 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(TRV26E/TRV27E/TRV36E/TRV46E:AEP,UK,EE,NE,RU)
< CONNECTOR >
CN451 1-766-646-21 CONNECTOR, FFC/FPC 10P
(TR713E/TRV16E/TRV26E/TRV27E/TRV27EP/TRV36E/TRV46E)
< DIODE >
D451 8-719-062-16 DIODE 01ZA8.2(TPL3)
(TRV16E/TRV26E/TRV27E/TRV27EP/TRV36E/TRV46E)
< IC >
IC451 8-759-489-19 IC uPC6756GR-8JG-E2 (TR713E/TRV46E)
< JACK >
J451 1-695-514-11 JACK (SMALL TYPE) 1P (HEADPHONE)
(TRV16E/TRV26E/TRV27E/TRV27EP/TRV36E/TRV46E)
< COIL >
L451 1-414-754-11 INDUCTOR 10uH (TR713E/TRV46E)
L453 1-216-295-91 SHORT 0
(TRV16E/TRV27EP/TRV46E:E,HK,AUS,CN)
L453 1-412-963-11 INDUCTOR 100uH
(TRV26E/TRV27E/TRV36E/TRV46E:AEP,UK,EE,NE,RU)
< RESISTOR >
R451 1-216-837-11 METAL CHIP 22K 5% 1/16W
(TR713E/TRV46E)
R452 1-216-837-11 METAL CHIP 22K 5% 1/16W
(TR713E/TRV46E)
R453 1-216-837-11 METAL CHIP 22K 5% 1/16W
(TR713E/TRV46E)
R454 1-216-837-11 METAL CHIP 22K 5% 1/16W
(TR713E/TRV46E)
R455 1-216-864-11 METAL CHIP 0 5% 1/16W
(TR713E/TRV46E)
R456 1-216-857-11 METAL CHIP 1M 5% 1/16W
(TR713E/TRV46E)
R458 1-216-833-11 METAL CHIP 10K 5% 1/16W
(TR713E/TRV46E)
R459 1-216-857-11 METAL CHIP 1M 5% 1/16W
(TR713E/TRV46E)
R461 1-216-835-11 METAL CHIP 15K 5% 1/16W
(TR713E/TRV46E)
R463 1-216-809-11 METAL CHIP 100 5% 1/16W
(TR713E/TRV46E)
PJ-90/91
