6-24
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
VC-215
< SENSOR >
SE451 1-803-041-11 SENSOR, ANGULAR VELOCITY (PITCH)
(TR713E/TRV46E)
SE452 1-803-041-21 SENSOR, ANGULAR VELOCITY (YAW)
(TR713E/TRV46E)
A-7094-113-A VC-215 (ZSL0PE) BOARD, COMPLETE
*******************************
(TR315E/TR415E/TR425E)
A-7094-114-A VC-215(ZB0) BOARD, COMPLETE (TR515E)
***************************
A-7094-115-A VC-215 (ZCB0) BOARD, COMPLETE (TR516E)
*****************************
A-7094-116-A VC-215(MMIB0) BOARD, COMPLETE (TR713E)
*****************************
A-7094-119-A VC-215(VMMIB0P) BOARD, COMPLETE
*******************************
(TRV46E)
A-7094-120-A VC-215(VZLB0) BOARD, COMPLETE (TRV36E)
**************************************
A-7094-203-A VC-215(VZL0P) BOARD, COMPLETE
*****************************
(TRV16E/TRV26E/TRV27E/TRV27EP)
(Ref. No. 1,000 Series)
< CAPACITOR >
C001 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C004 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C006 1-104-752-11 TANTAL. CHIP 33uF 20% 6.3V
C007 1-104-752-11 TANTAL. CHIP 33uF 20% 6.3V
C008 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C009 1-164-217-11 CERAMIC CHIP 150PF 5% 50V
C010 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C011 1-162-926-11 CERAMIC CHIP 82PF 5% 50V
C012 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C017 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C018 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C019 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C021 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C022 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C023 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C024 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C026 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C027 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C028 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C029 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C030 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C031 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C032 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C033 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C034 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C035 1-162-920-11 CERAMIC CHIP 27PF 5% 50V
C036 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C037 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C039 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C041 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C042 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C043 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C048 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C049 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C050 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C052 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C053 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C055 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C058 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C059 1-164-217-11 CERAMIC CHIP 150PF 5% 50V
C060 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V
C061 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C062 1-162-926-11 CERAMIC CHIP 82PF 5% 50V
C065 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C068 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
C069 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C070 1-162-908-11 CERAMIC CHIP 3PF 0.25PF 50V
C071 1-104-752-11 TANTAL. CHIP 33uF 20% 6.3V
C072 1-162-958-11 CERAMIC CHIP 270PF 5% 50V
C073 1-164-392-11 CERAMIC CHIP 390PF 5% 50V
C074 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
(TR515E/TR516E/TR713E/TRV36E/TRV46E)
C075 1-162-959-11 CERAMIC CHIP 330PF 5% 50V
(TR515E/TR516E/TR713E/TRV36E/TRV46E)
C075 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
(TR315E/TR415E/TR425E/TRV16E/TRV26E/TRV27E/TRV27EP)
C076 1-162-922-11 CERAMIC CHIP 39PF 5% 50V
(TR515E/TR516E/TR713E/TRV36E/TRV46E)
C078 1-162-928-11 CERAMIC CHIP 120PF 5% 50V
C079 1-162-922-11 CERAMIC CHIP 39PF 5% 50V
(TR515E/TR516E/TR713E/TRV36E/TRV46E)
C080 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
(TR515E/TR516E/TR713E/TRV36E/TRV46E)
C080 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
(TR315E/TR415E/TR425E/TRV16E/TRV26E/TRV27E/TRV27EP)
C081 1-162-916-11 CERAMIC CHIP 12PF 5% 50V
C082 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C083 1-162-924-11 CERAMIC CHIP 56PF 5% 50V
C085 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C086 1-115-156-11 CERAMIC CHIP 1uF 10V
C088 1-162-925-11 CERAMIC CHIP 68PF 5% 50V
(TR315E/TR415E/TR425E/TRV16E/TRV26E/TRV27E/TRV27EP)
C088 1-162-957-11 CERAMIC CHIP 220PF 5% 50V
(TR515E/TR516E/TR713E/TRV36E/TRV46E)
C089 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
(TR315E/TR415E/TR425E/TRV16E/TRV26E/TRV27E/TRV27EP)
C089 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
(TR515E/TR516E/TR713E/TRV36E/TRV46E)
C090 1-162-958-11 CERAMIC CHIP 270PF 5% 50V
C152 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C156 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C158 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C159 1-164-346-11 CERAMIC CHIP 1uF 16V
C160 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C161 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C163 1-135-180-21 TANTALUM CHIP 3.3uF 20% 6.3V
C166 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C168 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C169 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C170 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C182 1-135-149-21 TANTALUM CHIP 2.2uF 20% 10V
SE-80/81
