Sony CCD-TRV138 - LV Standard Data Input; Auto White Balance Standard Data Input

6-18
CCD-TRV138/TRV238E/TRV338/TRV438E
8. LV Standard Data Input
RadarW
RadarW
RadarW
RadarW
RadarW
Adjust the normal coefficient of the light value.
Mode CAMERA
Subject Clear chart
(Color reproduction adjustment frame)
Measurement Point Displayed data of page: 1 (Note 4)
Measuring Instrument Adjusting remote commander
Adjustment Page F
Adjustment Address 1A, 1B
Specified Value 0FE0 to 1020
Note 1: Perform “Flange Back Adjustment” before this adjust-
ment.
Note 2: Check that the data of page: 0, address: 10 is “00”.
Note 3: Check that the data of page: 6, address: 02 is “00”.
If not, turn the power of unit OFF/ON.
Note 4: The right four digits of the page: 1 displayed data of the
adjusting remote commander.
1:XX:XX
Displayed data
Switch setting:
1) NIGHTSHOT PLUS ........................................................ OFF
2) DIGITAL ZOOM (Menu setting) .................................... OFF
3) STEADYSHOT (Menu setting)
(CCD-TRV338/TRV438E only) ...................................... OFF
4) DISPLAY (Menu setting) ................................................LCD
Adjusting method:
Order Page Address Data Procedure
10 0101
26 4801
36 01 0D Press PAUSE button. (Note 5)
46 02
Check the data changes to
“01”.
50 031E
61
Check that the displayed data
(Note 4) satisfied specified
value.
Note 5: The adjustment data will be automatically input to page:
F, address: 1A and 1B.
Processing after completing adjustment:
Order Page Address Data Procedure
16 01 00 Press PAUSE button.
26 4800
30 0300
40 0100
9. Auto White Balance Standard Data Input
RadarWRadarWRadarW
Adjust the white balance reference at 3200K.
Mode CAMERA
Subject Clear chart
(Color reproduction adjustment frame)
Adjustment Page F
Adjustment Address 2A to 2D
Note 1: Perform “Color Reproduction Adjustment” before this
adjustment.
Note 2: Check that the data of page: 0, address: 10 is “00”.
Note 3: Check that the data of page: 6, address: 02 is “00”.
If not, turn the power of unit OFF/ON.
Switch setting:
1) NIGHTSHOT PLUS ........................................................ OFF
2) DIGITAL ZOOM (Menu setting).................................... OFF
3) STEADYSHOT (Menu setting)
(CCD-TRV338/TRV438E only)...................................... OFF
4) DISPLAY (Menu setting) ................................................ LCD
Adjusting method:
Order Page Address Data Procedure
10 0101
26 4801
36 01 11 Press PAUSE button.
46 01 0B Press PAUSE button. (Note 4)
56 02
Check the data changes to
“01”.
Note 4: The adjustment data will be automatically input to page:
F, address: 2A to 2D.
Processing after completing adjustment:
Order Page Address Data Procedure
16 01 00 Press PAUSE button.
26 4800
30 0100
