6-11
CCD-TRV138/TRV238E/TRV338/TRV438E
1-3. CAMERA SYSTEM ADJUSTMENTS
Before perform the camera system adjustments, check that the
specified values of “28 MHz Origin Oscillation Adjustment”, “LINE
OUT Level Adjustment” of “VIDEO SYSTEM ADJUSTMENT”
are satisfied.
Check that the data of page: 0, address: 10, is “00”.
If not, select page: 0, address: 10, and set data “00”
1. HALL Adjustment
RadarW
RadarW
RadarW
For detecting the position of lens iris, adjust the hall AMP gain
and offset.
Mode CAMERA
Subject Not required
Measurement Point Displayed data of page: 1 (Note 3)
Measuring Instrument Adjusting remote commander
Adjustment Page F
Adjustment Address 12 to 18
Specified value 87 to 8B during IRIS OPEN
15 to 19 during IRIS CLOSE
Note 1: Check that the data of page: 0, address: 10 is “00”.
Note 2: Check that the data of page: 6, address: 02 is “00”.
If not, turn the power of unit OFF/ON.
Note 3: The right two digits of the page: 1 displayed data of the
adjusting remote commander.
1:00:XX
Displayed data
Adjusting method:
Order Page Address Data Procedure
10 0101
26 9489
36 9517
46 01 6D Press PAUSE button. (Note 4)
56 02
Check the data changes to
“01”.
66 01 00 Press PAUSE button.
Note 4: The adjustment data will be automatically input to page:
F, address: 12 to 18.
Checking method:
Order Page Address Data Procedure
16 0C
Check that the data is “00” or
“10”.
20 0303
36 01 01 Press PAUSE button.
41
Check that the displayed data
(Note 3) during IRIS OPEN
satisfied the specified value.
56 01 03 Press PAUSE button.
61
Check that the displayed data
(Note 3) during IRIS CLOSE
satisfied the specified value.
Processing after completing adjustment:
Order Page Address Data Procedure
16 01 00 Press PAUSE button.
26 9400
36 9500
40 0300
50 0100
To Next Page
