3-1-6. Output Level and Impedance
Audio/Video output
AV MINIJACK:
Video signal: 1 Vp-p, 75 Ω (ohms), unbalanced, sync
negative
Audio signal: 327 mV (at output impedance more than
47 kΩ (kilohms))
Output impedance with less than 2.2 kΩ (kilohms)
3-1-7. Recording Mode (Standard 8/Hi8) Switching
The record mode (Standard 8/Hi8) of this unit switches as shown
in the following table. The playback mode (Standard 8/Hi8)
switches automatically according to the recording mode of the tape
played back.
Tape Used Recording Mode
ME Hi8
Hi8 MP
MP Standard 8
