6-10
CCD-TRV138/TRV238E/TRV338/TRV438E
8. F Page Table
Note 1: Check that the data of page: 0, address: 10 is “00”.
Note 2: Fixed data-1: Initialized data. (Refer to “1. Initializing
the 8, A, C, D, E, F, 1F Page Data”)
Fixed data-2: Modified data. (Refer to “2. Modification
of 8, A, C, D, E, F, 1F Page Data”)
Address
Initial value
Remark
NTSC PAL
10 80 80 28 MHz origin osillation adj.
11 Fixed data-1 (Initialized data)
12 50 50
Hall adj.
13 50 50
14 89 89
15 00 00
16 17 17
17 00 00
18 00 00
19 Fixed data-1 (Initialized data)
1A 36 36
LV standard data input
1B 00 00
1C to 29 Fixed data-1 (Initialized data)
2A 20 1E
Auto white balance
2B 05 36
standard data input
2C 07 07
2D F1 97
2E 15 13
Auto white balance adj.
2F 07 FC
30 0E 0E
31 85 14
32 Fixed data-1 (Initialized data)
33 36 36 Color reproduction adj.
34 Fixed data-1 (Initialized data)
35 28 27 Color reproduction adj.
36 to 39 Fixed data-1 (Initialized data)
3A FD FD
Color reproduction adj.
3B F5 F4
3C, 3D Fixed data-1 (Initialized data)
3E 2C 2C
Auto white balance adj.
3F 80 40
40 58 59
41 10 C0
42, 43 Fixed data-1 (Initialized data)
44 28 28
Flange back adj.
45 EC EC
46 35 35
47 8F 8F
48 13 13
49 B8 B8
4A 00 00
4B 00 00
4C 00 00
4D 00 00
4E 2B 2B Flange back adj.
Address
Initial value
Remark
NTSC PAL
4F 19 19
Flange back adj.
50 00 00
51 32 32
52 04 04
53 00 00
54 00 00
55 to 59 Fixed data-1 (Initialized data)
5A FF FF Optical axis adj.
5B to FF Fixed data-1 (Initialized data)
9. 1F Page Table
Note 1: If reading/writing data on pages 1F, set data: 01 to page:
0, address: 10, and then select pages F. By this data set-
ting, the pages 1F can be selected.
After the data reading/writing finished, return the data
on page: 0, address: 10 to “00”.
Note 2: Fixed data-1: Initialized data. (Refer to “1. Initializing
the 8, A, C, D, E, F, 1F Page Data”)
Fixed data-2: Modified data. (Refer to “2. Modification
of 8, A, C, D, E, F, 1F Page Data”)
Address
Initial value
Remark
NTSC PAL
00 to FF Fixed data-1 (Initialized data)
