CCD-TRV138/TRV238E/TRV338/TRV438E
6. D Page Table
Note 1: Check that the data of page: 0, address: 10 is “00”.
Note 2: Fixed data-1: Initialized data. (Refer to “1. Initializing
the 8, A, C, D, E, F, 1F Page Data”)
Fixed data-2: Modified data. (Refer to “2. Modification
of 8, A, C, D, E, F, 1F Page Data”)
Address
Initial value
Remark
NTSC PAL
10 00 00 Test mode
11, 12 Fixed data-1 (Initialized data)
13 Fixed data-2
14 to 21 Fixed data-1 (Initialized data)
22
23
24 Fixed data-2
25
26
27 to 29 Fixed data-1 (Initialized data)
2A
2B
Fixed data-2
2C to 35 Fixed data-1 (Initialized data)
36
37 Fixed data-2
38
39 Fixed data-1 (Initialized data)
3A Fixed data-2
3B to 55 Fixed data-1 (Initialized data)
56 Fixed data-2
57 Fixed data-1 (Initialized data)
58
59
Fixed data-2
5A to 6E Fixed data-1 (Initialized data)
6F Fixed data-2
70 to 7F Fixed data-1 (Initialized data)
7. E Page Table
Note 1: Check that the data of page: 0, address: 10 is “00”.
Note 2: Fixed data-1: Initialized data. (Refer to “1. Initializing
the 8, A, C, D, E, F, 1F Page Data”)
Fixed data-2: Modified data. (Refer to “2. Modification
of 8, A, C, D, E, F, 1F Page Data”)
Address
Initial value
Remark
NTSC PAL
00 to 30 Fixed data-1 (Initialized data)
31 Fixed data-2
32 to BF Fixed data-1 (Initialized data)
C0 Fixed data-2
C1 to FF Fixed data-1 (Initialized data)
