6-8
CCD-TRV138/TRV238E/TRV338/TRV438E
4. A Page Table
Note 1: Check that the data of page: 0, address: 10 is “00”.
Note 2: Fixed data-1: Initialized data. (Refer to “1. Initializing
the 8, A, C, D, E, F, 1F Page Data”)
Fixed data-2: Modified data. (Refer to “2. Modification
of 8, A, C, D, E, F, 1F Page Data”)
Address
Initial value
Remark
NTSC PAL
10 to 20 Fixed data-1 (Initialized data)
21 Fixed data-2
22 to 2B Fixed data-1 (Initialized data)
2C Fixed data-2
2D to 30 Fixed data-1 (Initialized data)
31 Fixed data-2
32 to 40 Fixed data-1 (Initialized data)
41 Fixed data-2
42 to 44 Fixed data-1 (Initialized data)
45 Fixed data-2
46 to 4B Fixed data-1 (Initialized data)
4C Fixed data-2
4D to 9C Fixed data-1 (Initialized data)
9D
9E
9F
Fixed data-2
A0 to FF Fixed data-1 (Initialized data)
5. C Page Table
Note 1: Check that the data of page: 0, address: 10 is “00”.
Note 2: Fixed data-1: Initialized data. (Refer to “1. Initializing
the 8, A, C, D, E, F, 1F Page Data”)
Fixed data-2: Modified data. (Refer to “2. Modification
of 8, A, C, D, E, F, 1F Page Data”)
Address
Initial value
Remark
NTSC PAL
10 to 13 Fixed data-1 (Initialized data)
14 00 00 Test mode
15 Fixed data-1 (Initialized data)
16 0B 0A
Switching position adj.
17 00 00
18 83 83 CAP FG offset adj.
19 30 30 AFC f
0
adj.
1A 68 62
LINE OUT level adj.
1B 62 62
1C, 1D Fixed data-1 (Initialized data)
1E B4 D7
REC Y current adj.
1F B4 D7
20 to 24 Fixed data-1 (Initialized data)
25 A0 A0 REC C/AFM current adj.
26 to 2E Fixed data-1 (Initialized data)
2F A6 A6 1.5 MHz deviation adj.
30 80 80 BPF f
0
adj.
31 to 4F Fixed data-1 (Initialized data)
50 67 79
LCD level adj. (VCO adj.)
51 79 67
52 84 84 LCD V-COM adj.
53 to 55 Fixed data-1 (Initialized data)
56 87 87
LCD White balance adj.
57 68 68
58 AF AF LCD level adj. (Contrast adj.)
59 to F3 Fixed data-1 (Initialized data)
F4 00 00
F5 00 00
F6 00 00
F7 00 00
F8 00 00
F9 00 00
Emergency memory
FA 00 00
FB 00 00
FC 00 00
FD 00 00
FE 00 00
FF 00 00
