6-3
CCD-TRV138/TRV238E/TRV338/TRV438E
• Adjusting items when replacing a board or EEPROM
When replacing a board or EEPROM, adjust the items indicated by z in the following table.
Table 6-1-1 (2)
Replaced part
Adjustment Section Adjustment
(COMPLETE) (COMPLETE) (EEPROM)
PD-204 board VC-341 board VC-341 board IC602 Supporting
Initialization of 8, A, C, D,
E, F, 1F page data
Initializing of 8, A, C, D, E, F, 1F page
data
zz
Camera HALL adj. zzz
Flange back adj. zzz
Optical axis adj. zz
Color reproduction adj. zz
LV standard data input zzz
AWB standard data input zzz
Auto white balance adj. zzz
Angular velocity sensor output check
and steadyshot check (Note 3)
zzz
LCD LCD level adj. zzzz
LCD V-COM adj. zzz
LCD White balance adj.
zzz
Servo CAP FG offset adj. zzz
Switching position adj.
zz
Video 28 MHz origin osillation adj. zz
AFC f
0 adj. zzz
LINE OUT level adj. zz
REC Y current adj. zz
REC C/AFM current adj.
zz
Audio BPF f
0 adj. zz
1.5 MHz deviation adj.
zz
Mechanism Tape path adj.
