Sony DME-3000 - DVS-2000 C Digital Video Switcher Connections

13(E)
!
MODEL DVS-2000C
KV
V
VK/Z
K/Z
BKGD
K
V
DVS-2000C Digital Video Switcher Connections
DVS-2000C Digital Video Switcher connections
BKDS-2010 Switcher Control Panel
DVS-2000C Digital Video Switcher
DME-3000/7000
DME
DIGITAL
OUTPUTS
VIDEO
COMBINER
OUTPUTS
EXT/C
c)
AUX BUS
OUTPUTS
PRIMARY
INPUTS
AUX
COMBINER
INPUTS EXT/C
: 9-pin/25-pin remote
control cable
: Video signals
: 75-ohm coaxial cable
: KEY signal
: KEY/Z signal
: Background signals
a) Only when the optional BKDM-3050 board is
installed.
b) These connectors are provided only on the DME-7000.
c) When the optional BKDM-3050 board is not installed,
output key signals from the DIGITAL OUTPUTS
KEY connector of the DME-3000/7000.
d) When the optional BKDM-7020 board is not installed.
e) When the optional BKDM-7020 board is installed.
DIGITAL
INPUTS
DIGITAL
INPUTS
BKDM-3010 DME
Control Panel
b)
b)
BKGD
a)
VIDEO/Y/
EXT
d)
e)
