20(E)
Specifications
BKDM-3020 Composite Digital
Input/Output Board
General
Power requirements
5 V ± 0.2 V DC
–5 V ± 0.1 V DC
12 V ± 1 V DC
Power consumption
40 W
Temperature range
Operation guaranteed: 5˚C to 40˚C (41˚F to 104˚F)
Performance guaranteed: 10˚C to 35˚C (50˚F to
95˚F)
Dimensions 317 × 20 × 380 mm (12
1
/2 ×
13
/16 ×
15 inches) (w/h/d, excluding
projections)
Mass 1.2 kg (2 lb 10 oz)
Input/output
Input Composite serial digital signal
(VIDEO A/B, KEY A/B)
Reference signal (black burst)
Output Composite serial digital signal
(VIDEO 1/2, KEY 1/2)
BKDM-3021 Component Digital
Input/Output Board
General
Power requirements
5 V ± 0.2 V DC
–5 V ± 0.1 V DC
12 V ± 1 V DC
Power consumption
40 W
Temperature range
Operation guaranteed: 5˚C to 40˚C (41˚F to 104˚F)
Performance guaranteed: 10˚C to 35˚C (50˚F to
95˚F)
Dimensions 317 × 20 × 380 mm (12
1
/2 ×
13
/16 ×
15 inches) (w/h/d, excluding
projections)
Mass 1.2 kg (2 lb 10 oz)
Related equipment
BKDM-3010 Control Panel for DME-3000/7000
DVS-2000C Digital Video Switcher
DVS-2100C Digital Video Switcher
BKDS-2010 Control Panel for DVS-2000C/2100C
DVS-6000/6000C Digital Video Switcher
BKDS-6010 Control Panel for DVS-6000/6000C
DVS-7000 Digital Video Switcher
BKDS-7011/7012/7021/7022/7023 Control Panel for
DVS-7000
BKDS-6050 Key Frame Control Panel for DVS-6000/
6000C
BKDS-7030 Key Frame Contorl Panel for DVS-7000
BKDS-7031 DME Control Panel for DVS-7000
BVE-2000/9100 Editing Control Unit
BKDM-3010 DME Control Panel
General
Power requirements
10 V to 15 V DC
Power consumption
12 W
Temperature range
Operation guaranteed: 5˚C to 40˚C (41˚F to 104˚F)
Performance guaranteed: 10˚C to 35˚C (50˚F to
95°F)
Storage: –20˚C to +60˚C (–4˚F to +140˚F)
Dimensions 424 × 84 × 285 mm (16
3
/4 × 3
3
/8 ×
11
1
/4 inches) (w/h/d, excluding
projections)
Mass 3.5 kg (7 lb 11 oz)
Input/output connectors
PROCESSOR D-sub 25-pin, female
MONITOR D-sub 15-pin, female
SPARE D-sub 9-pin, male
